Install
Vertical installation/horizontal installation
Memory Capacity
JOB: 200000 steps,10000 robot commands (total 200M)
Operation Mode
Teaching/replay/remote
Power OnAnd Off IntervalTime
10S
Standard I/O
Universal digital IO: standard 16 input and 16 NPN input (expandable)
Display
1*VGA:max resolution up 2560 X1600@60Hz
Expansion Slot
16 input/16 expansion 10 module
|
|
|
2 high-speed encoder signal interface (for tracking)
|
|
|
|
1*RS232/422/485
|
|
|
|
3*RJ45Inteli211ATGbE (10/100/1000Mbps)
|
|
|
|
Support CAN, ModbusTCP, CC-Link, TCPIP,etc.
|
|
|
Input Voltage Range
Rated 1PH 220VAC 50/60HZ (the input voltage is within + 7% of the rated voltage)
EMC Test Environment
Support IEC61000-6-2
Installation Environment
Temperature:0~55°C,Humidity:10~80%RH(no condensing),Below 1000M
Dimensions(WDH)
390(width)*474(depth)*265(height)mm
Supported Models (Standard Configuration)
MB25SC/MR30C/MB15/MB20/MB10C/MB25
